Antennas and National Monuments

We started SolderSmoke 185 with a brief description of my recent ascent to the top of the Washington Monument. A few days later I was visiting George K9GDT’s wonderful web site
http://www.qsl.net/k9gdt/radio/radio.htm and in the humor section came across the above Gil cartoon from 1959. That is the general idea.

Pete then sent me this:

Pete originally had a three element Yagi coming out of Teddy Roosevelt’s head, but that just wasn’t right. I asked that it be changed to a 17 meter Moxon. Thanks Pete.

I would like to note for the record that I have no intention of using the Washington Monument, the Statue of Liberty, Mount Rushmore or any other national monuments as supports for any Yagis, Moxons, Cubical Quads, Ray Guns, Lazy H’s, Inverted L’s or any other type of electromagnetic wave launcher.

Breadboarding and Mountaintopping


We needed an illustration today. I was having trouble finding something suitable. Then the Radio Gods (along with Joe Peltola and the artist N0UJR) provided this. Obviously I can relate to the breadboard operation. I’m sure Pete can too. As for the mountain topping, that made me think of Colin, M1BUU. And of Wes, W7ZOI.

Our book: “SolderSmoke — Global Adventures in Wireless Electronics” http://soldersmoke.com/book.htm Our coffee mugs, T-Shirts, bumper stickers: http://www.cafepress.com/SolderSmoke Our Book Store: http://astore.amazon.com/contracross-20

Inducted Into Shortwave Rogues’ Gallery

Jeff Murray, K1NSS, has done me the honor of placing me in his VERY ELITE Friends of Shortwave “Rogue’s Gallery.” Check it out: http://dashtoons.com/FOSW.html
Kind of ironic that I should be recognized for my work on regens!
Thanks Jeff!

Our book: “SolderSmoke — Global Adventures in Wireless Electronics” http://soldersmoke.com/book.htm Our coffee mugs, T-Shirts, bumper stickers: http://www.cafepress.com/SolderSmoke Our Book Store: http://astore.amazon.com/contracross-20

Sometimes the Receivers Seem to Almost Self-Assemble

I’ve been building shelves for my wife. So I end up with all these nice pieces of pine, just the right size for the base of a breadboard receiver and a very sturdy cabinet to surround it. Then I find in the junk box two nice variable caps and this old pill bottle coil (with tickler!) that I wound in 1998; I figure they will resonate from around 5 – 15 MHz. Then Jeff Murray, K1NSS does that poster about Dave Richards, AA7EE (scroll down) in which he mentions the virtues of a National Velvet Vernier reduction drive — I have one of those too. And then there is the copper-clad board (from AL7RV/W8NSA) that would be perfect for the front panel. You see where this is going, right? My friends, I am once again on the road to shortwave regeneration. It will have an Armstrong detector with throttle cap.

Our book: “SolderSmoke — Global Adventures in Wireless Electronics” http://soldersmoke.com/book.htm Our coffee mugs, T-Shirts, bumper stickers: http://www.cafepress.com/SolderSmoke Our Book Store: http://astore.amazon.com/contracross-20

Youth, Short Waves, and the Invigorating Properties of Regen Receivers

Oh man, when I saw this I just had to put it on the blog. The artist is Jeff Murray, K1NSS, the genius behind Dashtoons. Dave Richards AA7EE is, well, the OC!

So not only have we learned that regen receivers are NOT demonic, we now see that they have health enhancing properties! Like all that antioxidant stuff! This is great. I’m feeling younger already.

Regen on my friends!

Our book: “SolderSmoke — Global Adventures in Wireless Electronics” http://soldersmoke.com/book.htm Our coffee mugs, T-Shirts, bumper stickers: http://www.cafepress.com/SolderSmoke Our Book Store: http://astore.amazon.com/contracross-20

Steve Smith (on the left) and Bill (with the filter)

Steve “Snort Rosin” Smith has been keeping me on the side of the angels (and the FCC regs) in the area of harmonic filtering. Today he sent me this Steve and Bill cartoon. Thanks Steve. Just what I needed as I prepare for my next attempt to get my JBOT (with filter!) to behave. Wish me luck!

Our book: “SolderSmoke — Global Adventures in Wireless Electronics”http://soldersmoke.com/book.htmOur coffee mugs, T-Shirts, bumper stickers: http://www.cafepress.com/SolderSmokeOur Book Store: http://astore.amazon.com/contracross-20

WONDERMARK! (Comics with the Knack)

As part of our occasional series on Knack-related comic strips, today we present Wondermark. This link will take you to the first page: http://wondermark.com/tink1/ From there, look for the little “NEXT” hand on the right of the comic. There are eight. All of them are gems. Also, be sure to check out the author’s bio:
http://wondermark.com/about/
